Deks 6010 DN150 PVC Rubber Joiner Coupling OD 155-165mm

Overview

The Deks 6010 Black EPDM Rubber Jenco Joiner Flexible Coupling is designed to connect or repair DN150 PVC pipes (pipe OD 155–165 mm) in non-pressure applications such as drain and soil waste systems. Constructed from a highly flexible rubber polymer and equipped with 316 stainless steel adjustable bands, it provides excellent durability and ease of installation. It is Australian Watermark Approved and complies with AS/NZS 4327, offering peace of mind to plumbers.

Technical Details

• Manufacturer: Deks
• Model / SKU: 6010
• Material: EPDM Rubber, 316 Stainless Steel Bands
• Connection Type: PVC to PVC
• Pipe Size Compatibility: DN150 PVC (155–165 mm OD)
• Max Temperature: Continuous: 38°C – Intermittent: 60°C

Dimensions

• Inner Diameter: DN150 PVC
• Outer Diameter: 177.2 mm
• Stack Height: 125 mm
• Stainless Steel Band Width: 12.7 mm

Package Contents

• Deks 6010 Joiner
• Weight: 830 g
